SESNET (Simplified Electroslag Welding Process with Nonconsumable Elevating Tip is used for welding slag welding wire electrode, through the consumption of electricity slag torches and conductive mouth into slag pool of electric equipment,  mainly used for Vertical welds efficient structural steel welding, especially suitable for box beam and column partition of welding.

1, application range:

+  steel plate thickness:  6 ~ 100mm

+  apply in kinds: low carbon steel, low alloy steel, medium carbon steel, refractory steel, etc

+  the maximum length weld 1280 mm (dependent on electricity slag welding-torch length),

+  weld structure: T weld and butt-welded seam
2, characteristic

+ with fine wire, high current density make deposition rates to  the 140g/min, and at once, thus forming welds welded with high efficiency.

+ the application of welding torch swing can suit to maximum thickness of welding 100mm (other manufacturer can welding plate thickness is only 16 ~ 65mm range).

+ specially designed welding current detection control system and ammeter pointer  high reliability, high precision and dynamic characteristics.

+ easy to operate, according to the pre -set current ,automatic lift welding torch slag, so a operators can also control more than two machines.

+ only use wire filling welding materials as filler material ,so low cost than SES way.

+ low equipment maintenance cost. Using market can provide cost-effective and high reliability, reduce the cost of using user end.

+  slow feed wire start arc welding and cutting ball (FTT) function, make more reliable and cancel the process  for  cutting crater arc welding welding ball.

+ motor overloaded and short circuit protection function, can avoid motor stall and short-circuit damage elements.

+  including three coordinates adjustment, rotate, cross direction Angle adjustment and wires cross straightening function, can adjust the convenient location, slag, torch welding torch to end in the axis.

3, technical parameters

+ welding rated current: 600A

+ the rated voltage: 60V

+ the rated load duty rate: 100%

+ wire speed: 1.5 ~ 15m/min

+  Electric welding torch location adjustment range:

Vertical     160mm

Level        90mm

Transverse   50mm

Rotate Angle    360 °

+  torch lifting speed: 0 ~ 130mm/min

+  Electric torch Angle adjustment: slag in the direction of ± 3 degrees (the X and Y axes)

+  Electric slag welding-torch length: 600 ~ 1600mm   100mm (class)

+  swinging track: reciprocating linear motion : 0 ~ 100mm

+  Swing speed: 0 ~ 1600mm/min

+  Max swing frequency: 0 ~ 8 back/min (max swing amplitude)

+  Swing dwell time:  1 ~ 12s ( adjustable respectively on left or right)
