1.Summarize:

The welding equipments which used with submerged arc single side welding root shaped ( flux over copper interleaver covers up the arc welding method, the brief name FCB method) is a high-efficiency welding method that used for the large steel plate material conjunction. Including MP-2500 steel plate butt-welding machine, transport roller, side fixed position framework.

2.Technical data

Apply steel plate width:        ≤2500 ｍｍ

Apply steel plate thickness:   8-25 ｍｍ

Apply steel plate longth:       2000-11000ｍｍ

Welding speed:                       150-2400 mm/ min

Flux recovery system:             ZH-100

Horizontal cutting speed :     100-1000 mm/ min

Welding power:                   Lincoln DC-1500+ AC-1200( selection )

Fixed position method:      Electromagnetism cupules and anti- transform

Electromagnetism cupules:   0.8 T ×8 pcs
